Transfer Switch TCS2P125-22M | 125 Amps (2 Pole) 50/60 HZ | UL Rated | Compact Design| Made in USA!
Garden & Outdoor

Thunder Parts

Thunder Parts TCS2P125-22M Transfer Switch Blue

$849.99
Brand Thunder Parts
Category Transfer Switches
GTIN / UPC 793155236232

“Add to cart” starts a direct order with Eco Sweet Home. A link labeled for Amazon or another retailer takes you to that retailer, which then handles the transaction under its own terms.

View full product details
Shipping destinations, methods, costs and estimates are shown at checkout for eligible direct orders.
Questions? Contact Eco Sweet Home at info@ecosweethome.com.
Find supplies for gardening, patio living and outdoor projects in one store.

Product Details

Original listing and package details

Transfer Switch TCS2P125-22M | 125 Amps (2 Pole) 50/60 HZ | UL Rated | Compact Design| Made in USA!

Brand: Thunder Parts

Model: TCS2P125-22M

Color: Blue

Features

  • Rated Voltage 250Vac. Rated Current 125Amp. Modular design for installation next to switch or on the door Electrically or manually operated, mechanically held contacts Adjustable time delay in neutral position
  • Compact size with user-friendly status LED display Monitor Normal & Standby source OV and UV Built-in 1 to 4 weeks with / without load exerciser
  • Made with UL 94V-0 plastic Build-in neutral lug module Designed for telecom industry or home ATS applications
  • Rated Frequency: 50/60Hz Switch Type: Double throw with Neutral position
  • Operating Current: 3.0 KA / 1 second @ 250 Vac Short Circuit Peak Value: 7.5 KA Utilization Category: AC-33A* Operation Life: Over 6000 times / with load
  • Rated Operating Voltage: TCS2P125-11 90 to 140 Vac TCS2P125-22 180 to 270 Vac ATS Class: PC Connection: Front
  • Over Volt Setting: 110 to 280 Vac (adjustable) Over Volt Reset Below: 10 Vac of the OV setting Under Volt Setting: 80 to 230 Vac (adjustable) Under Volt Reset Exceed 10 Vac of the UV setting
  • Normal ON Capacity: 7A @ 250 Vac Max. Standby ON Capacity: 7A @ 250 Vac Max. Remote Start Capacity: 6A @ 277 Vac. 6A @ 28 Vdc Max
  • Power Consumption: Less than 1W Panel Cut-Out: 47.0 x 162.0 +/-0.5 mm

Details

The Thunder Parts TCS2P125-22M transfer switch supports electrically or manually operated, mechanically held contacts with an adjustable neutral-position time delay. It includes a status LED display, normal and standby source over- and undervoltage monitoring, an exerciser with or without load, and a built-in neutral lug module for telecom or home ATS applications.

UPC: 793155236232
